Hot Rodded Plexi AH Deluxe 100

  • $ 1,780.00

Model Descriptions:

The Ceriatone AH Deluxe is a continuation of our effort in providing guitar players with an affordable, yet versatile, and feature laden tube amplifier.

The Ceriatone AH Deluxe is a 3 channel witching amp, with Clean and 2 gain channels (OD, and HOD).

The Clean channel can be pristine, rich and lush, or even do blues breakups, while the gain channels can go from light crunch, rock, and even the heaviest of metals, and anything in between.

The OD and HOD gain channels each has its own Gain and Master controls, allowing smooth transition between channels, without volume jumps. Go Clean, Dirty, and then Solo easily!

Furthermore, there are various tonal switch options provided, allowing you to fine tune your sounds, and discover new territories!

The Ceriatone AH Deluxe is equipped with a series solid state buffered loop that is transparent, and will do well with your effects pedals.

A Line Out with a level control makes it convenient for you to plug into power amps, certain effects, or recording consoles.

Handwired on turret board (not PCB), using the best components, and craftsmanship that can only result from labor of love!

Head Dimension : 26 x 9 x 10.35 inches / Actual Weight : 26.0kg

YouTube Video Thumbnail
AH Deluxe 100 - Clip 1
YouTube Video Thumbnail
AH Deluxe 100 - Clip 2
YouTube Video Thumbnail
AH Deluxe 100 - Clip 3
YouTube Video Thumbnail
AH Deluxe 100 - Clip 4
Specifications
Power Output
  • 100 Watt
  • Feature Overview
  • Channel Switching amp with Clean and 2 Gain Channels (OD + HOD)
  • Clean Channel: Volume, Treble, Middle, Bass, and Bright Switch

  • Gain Channels (Shared EQ):
  • OD Channel: Gain, Treble, Middle, Bass, Master Volume
  • HOD Channel: Gain, Treble, Middle, Bass, Master Volume
  • Multiple tone shaping controls: “Voice”, “Structure”, “Thick”, “S”, “Era”

  • Global NFB, Resonance Controls
  • Series Buffered Loop with Return Level
  • Line Out Jack with Level control
  • Hand Wired on Turret Board with the best components
  • DC heaters for low noise floor
  • Tubes
  • Power: 4 x EL34
  • Preamp: 4 x 12AX7/ECC83
  • Rectifier: Solid State
  • Complete Amp
    Head
    Complete Head Unit
    $ 1,780.00
    28.0 KG
    Full working chassis in head cabinet. Footswitch included.
    Options
    Without tubes
    $ 1,580.00
    28.0 KG
    Full working chassis without tubes in head cabinet. Footswitch included.
    Without head cabinet
    $ 1,560.00
    22.0 KG
    Full working chassis without head cabinet. Footswitch included.
    Without head cabinet and tubes
    $ 1,360.00
    22.0 KG
    Full working chassis without tubes and head cabinet. Footswitch included.
    Kits
    AHD 100 Kits
    Package 1
    $ 620.00
    10.0 KG
    All components with unassembled board, front plate, rear plate, and chassis. No OT, no PT, no choke, no tubes and no cabinet. Footswitch included.
    Package 2
    $ 900.00
    22.0 KG
    All components with unassembled board, front plate, rear plate, chassis, choke, OT and PT. No tubes and no cabinet. Footswitch included.
    Package 1 with assembly
    $ 1,080.00
    10.0 KG
    All components with assembled board, front plate, rear plate, and fully assembled in chassis. No OT, no PT, no choke, no tubes and no cabinet. Footswitch included.
    Add-On/Parts
    Board
    Unassembled board
    $ 250.00
    2.5 KG
    Cabinet
    Head
    $ 220.00
    22.0 KG
    Weight is for empty head cabinet only
    Chassis
    Steel
    $ 80.00
    5.0 KG
    Laser Punched Steel, Thickness 1.5 mm
    Faceplate
    Front plate
    $ 30.00
    1.5 KG
    Plexi/Acrylic, Reversed Silk Screened
    Rear plate
    $ 30.00
    1.5 KG
    Plexi/Acrylic, Reversed Silk Screened
    Trannies
    Power & Output Trans & Choke
    $ 280.00
    15.0 KG
    Tubes
    EL34 x 4, 12AX7 x 4
    $ 200.00
    3.5 KG
    Documentation
    Layout
    AH Deluxe 100 Layout
    AH Deluxe 100 Manual
    Manual
    AH Deluxe 100 Layout
    AH Deluxe 100 Manual

    Layout

    AH Deluxe 100 Layout

    Manual

    AH Deluxe 100 Manual
