British Style 18W

  • $ 1,075.00

Model Descriptions:

The Ceriatone 18W will ALWAYS have a special place in our hearts.  This design, and it’s many variants, served as the impetus for Ceriatone.

In case you’ve never been on the Internet, the British Series 18W is an amplifier design that had a resurgence in popularity largely due to DIY communities.

The 18W standard features two channels, each with a tone control.  One channel has a dedicated tremolo circuit, while the other tends to have more available gain.  This circuit is capable of fantastic clean and crunch tones, and the cathode-biased EL84 section adds it’s characteristic harmonic swirl.

True to the original design, the chassis is to be mounted in a combo cabinet.

Like other Ceriatone amps, we have labored carefully to select the finest components to suit the design, and the 18W uses our specially designed, custom transformers for superior reliability, frequency response, and feel.

Head Dimension : 25.75 x 8.35 x 10.35 inches / Actual Weight : 16 kg

Combo 1×12 Dimension : 24 x 10.5 x 21 inches / Actual Weight Sans Speaker : 20kg

Combo 2×12 Dimension: 28 x 10.5  x  21 inches / Actual Weight Sans Speakers:

Specifications
Power Output
18 Watt
Feature Overview
  • Dual channel (Normal, Tremolo) with dual inputs (high, low gain)
  • Channel Volume and Tone controls
  • All-Tube Tremolo with Speed and Intensity Controls
  • Footswitchable Tremolo control (on/off)
  • Tubes
  • Power: 2 x EL84
  • Preamp: 3 x 12AX7/ECC83
  • Rectifier: EZ81
  • Complete Amp
    Head
    Complete Head Unit
    $ 1,075.00
    23.0 KG
    Full working chassis in head cabinet. Footswitch included.
    Options
    Without tubes
    $ 955.00
    23.0 KG
    Full working chassis without tubes in head cabinet. Footswitch included.
    Without head cabinet
    $ 890.00
    12.0 KG
    Full working chassis without head cabinet. Footswitch included.
    Without head cabinet and tubes
    $ 770.00
    12.0 KG
    Full working chassis without tubes and head cabinet. Footswitch included.
    Combo
    Combo 1x12
    $ 1,140.00
    35.0 KG
    Full working chassis in combo 1x12 cabinet, sans speaker. Email us to enquire on speaker choice. Footswitch included.
    Combo 2x12
    $ 1,165.00
    59.0 KG
    Full working chassis in combo 2x12 cabinet, sans speakers. Email us to enquire on speaker choice. Footswitch included.
    Kits
    Package 1
    Head/Combo
    $ 420.00
    5.0 KG
    All components with unassembled board, front plate, rear plate, and chassis. No OT, no PT, no tubes and no cabinet. Footswitch included.
    Package 2
    Head/Combo
    $ 540.00
    12.0 KG
    All components with unassembled board, front plate, rear plate, chassis, OT and PT. No tubes and no cabinet. Footswitch included.
    Package 1 with assembly
    Head/Combo
    $ 650.00
    7.0 KG
    All components with assembled board, front plate, rear plate, and fully assembled in chassis. No OT, no PT, no tubes and no cabinet. Footswitch included.
    Add-On/Parts
    Board
    Unassembled board
    $ 120.00
    2.5 KG
    Cabinet
    Head
    $ 185.00
    21.0 KG
    Weight is for empty head cabinet only
    Combo 1 x 12 cabinet
    $ 250.00
    35.0 KG
    Price and weight is for empty combo cabinet, without speaker. Email us to enquire on speaker choice.
    Combo 2 x 12 cabinet
    $ 275.00
    59.0 KG
    Price and weight is for empty combo cabinet, without speaker. Email us to enquire on speaker choice.
    Chassis
    Aluminum (head / combo)
    $ 75.00
    4.0 KG
    Laser Punched Alum, Thickness 2.0 mm
    Faceplate
    Front plate
    $ 28.00
    1.5 KG
    Plexi/Acrylic, Reversed Silk Screened
    Rear plate
    $ 28.00
    1.5 KG
    Plexi/Acrylic, Reversed Silk Screened
    Trannies
    Power & output trans
    $ 120.00
    6.5 KG
    Tubes
    3 x 12AX7, 2 x EL84 , 1 x EZ81
    $ 120.00
    3.5 KG
    Documentation
    Layout
    British Style 18 Watt

    Layout

    British Style 18 Watt
