American Classics PrinzeTone

  • $ 985.00

Model Descriptions:

The classic American amplifiers of the ‘50s and ‘60s inspired us to create the, errrrr, American Classic series.

The Ceriatone Prinzetone amplifier is based on the dual 6V6 1×10 combo made in the mid and late ‘60s.

Compared to others in this series, the Prinzetone has a more traditional “blackface” tonestack known for its clarity and musical, yet subdued midrange.  We have improved the midrange response, and also added a neat boost switch that defeats the tonestack.  With the Boost engaged, the breakup and frequently response are both decidedly more “tweed” in nature.

We also kept the amazing tremolo circuit, which we believe is superior to the later “optical”-type tremolo seen in the larger “blackface” amplifiers of this period.

Like other Ceriatone amps, we have labored carefully to select the finest components to suit the design, and the Prinzetone uses our specially designed custom transformers for superior reliability, frequency response, and feel.

Head Dimension : 15.5 x 8.35 x 9.75 inches / Actual Weight : 13 kg

Combo 1×12 Dimension : 18.35 x 10.35 x 21.5 inches / Actual Weight Sans Speaker : 19 kg

YouTube Video Thumbnail
Prinzetone - Clip 1
YouTube Video Thumbnail
Prinzetone - Clip 2
Specifications
Power Output
17 Watt
Feature Overview
  • Single channel
  • Volume, Bass, Treble, Tremolo Speed, and Tremolo Intensity Controls
  • Boost switch
  • NFB control
  • Footswitchable Tremolo On/Off
  • Tubes
  • Power: 2 x 6V6
  • Preamp: 2 x 12AX7/ECC83
  • Rectifier: 1 x 5AR4 / GZ34
  • Complete Amp
    Head
    Complete Head Unit
    $ 985.00
    16.0 KG
    Full working chassis in head cabinet. Footswitch included.
    Options
    Without tubes
    $ 860.00
    16.0 KG
    Full working chassis without tubes in head cabinet Footswitch included.
    Without head cabinet
    $ 855.00
    11.0 KG
    Full working chassis without head cabinet. Footswitch included.
    Without head cabinet and tubes
    $ 730.00
    11.0 KG
    Full working chassis without tubes and head cabinet. Footswitch included.
    Combo
    Complete Combo 1x12 Unit
    $ 1,075.00
    31.0 KG
    Full working chassis in combo 1x12 cabinet, sans speaker. Email us to enquire on speaker choice. Footswitch included.
    Kits
    Package 1
    Head/Combo
    $ 400.00
    5.0 KG
    All components with unassembled board, front plate, rear plate, and chassis. No OT, no PT, no tubes and no cabinet. Footswitch included.
    Package 2
    Head/Combo
    $ 530.00
    11.0 KG
    All components with unassembled board, front plate, rear plate, chassis, OT and PT. No tubes and no cabinet. Footswitch included.
    Package 1 with assembly
    Head/Combo
    $ 600.00
    6.0 KG
    All components with assembled board, front plate, rear plate, and fully assembled in chassis. No OT, no PT, no tubes and no cabinet. Footswitch included.
    Add-On/Parts
    Board
    Unassembled board
    $ 130.00
    2.5 KG
    Cabinet
    Head
    $ 130.00
    15.0 KG
    Weight is for empty head cabinet only
    Combo 1 x 12 cabinet
    $ 220.00
    29.0 KG
    Price and weight is without speaker(s). Email us to enquire on speaker choice.
    Chassis
    Steel
    $ 80.00
    4.0 KG
    Laser Punched Steel, Thickness 1.5 mm
    Faceplate
    Front plate
    $ 30.00
    1.5 KG
    Plexi/Acrylic, Reversed Silk Screened
    Trannies
    Power & output trans
    $ 130.00
    6.0 KG
    Tubes
    1x GZ34, 2 x 6V6GT, 2 x 12AX7
    $ 125.00
    3.5 KG
    Documentation
    Layout
    American Classics PrinzeTone

    Layout

    American Classics PrinzeTone
